Name Configuration
Motherboard J1900 quad-core four-thread 2.0GHz support Baytrail processor
Memory Notebook DDRIII 4G
Hard Disk M-SATA 64G electronic hard drive
Monitor Main screen: 15.6’ TP touch Sub screen: 13.3 inches
Resolution 1920*1080
Onboard Amplifier Inline channel speaker
Printer Built-in large gear 58mm thermal printer
Scanner Embedded barcode, QR code white light scanning module
Port COM: 2* external RS232 interface LAN: 1* external 10/100M adaptive network interface
DC power supply: 1*12V built-in display power output interface, 1*12V external power input interface
VGA: 1* display signal output interface EDP: 2* built-in display interface
Audio: 1* external audio line input interface, 1* external audio output interface
USB: 6* external interface, 4* built-in interface
Operating system support Windows 7 and above
Power Hangjia 12V7A Power Adapter
Color Metallic color
Other Operating Environment: Working Environment Temperature: -20-60°C Working Environment Humidity: 0-90%
Optional Accessories Main screen: 13.3’’TP touch Secondary screen: 15.6-inch full-plane LCD monitor Printer: 80MM thermal tape printer embedded
Operating system support: Android keyboard: KB102 black Money box: 405 neutral black
